Non Pressurized Vacuum Tube Solar Water Heater - China
price: check with company for price
200L Homed Thermosiphon Integrated Non Pressurized Vacuum Tube Solar Water Heater - - - - Tube QTY | Tube size | Water Capacity(L) | Supply ability | QTY in 20GP/40HQ | 10 | 58*1800mm | 100L | 1--2 people | 68/165 | 15 | 58*1800mm | 150L | 2--3 people | 53/128 | 20 | 58*1800mm | 200L | 3--4 people | 40/97 | 24 | 58*1800mm | 240L | 4--5 people | 34/82 | 30 | 58*1800mm | 300L | 5--6 people | 28/68 | 36 | 58*1800mm | 360L | 6--7 people | 24/57 | 42 | 58*1800mm | 420L | 7--8 people | 20/50 | - - - - How non-pressurized solar water heater works? 1 - Non-pressurized solar water heater of all glass evacuated tube collector integrated with storage tank, are ideal for use in houses and other applications where cheap, reliable hot water supply is required.
They are simple, economic and practical.
2 - As the specific gravity of hot water and cold water are different, cold water goes downward and hot water goes upward.
3 - When cold water in evacuated tubes is heated, it becomes lighter and goes to the water tank, while cold water in the tank goes down to the evacuated tubes.
4 - Through this circulation, the cold water in the water tank will be gradually heated.
- - - - Description | Compact non solar water heater Galvanized steel | Material of outer tank | Galvanized steel or Stainless steel 201 or Stainless steel 304 | Material of inner tank | Stainless steel 304-2B | Material of bracket | Galvanized steel or Stainless steel 201 or Stainless steel 304 or Aluminum | Insulation foam thickness | 50mm-65mm Polyurethane | Vacuum tubes | 58*1800mm/47*1500mm | Accessories | Anti-aging silicon seals, Dust-proof seals, Air-vent cap, Stainless screws | Auxiliary Devices | Assistant tank, Intelligent controller, Electrical heater, Magnesium anodes | Tilt Angle | 18 ~ 45 | Water Output | 45 - 99C | - - - - Assistant tank: Used to fill the water into big water tank automatically.
Magnesium Rod: It can help the equipment of the solar heater system such as the water tank, the evacuated tubes etc.
Preventing water incrustation, melting silt and preventing erosion by lower cost.
Electric Heater: Used to heat water in rainy days or evening nights when water not enough hot.
Controller: Display panel with Connection box 1 - Sensor can test the water temperature and capacity in tank.
2 - Electric valve for filling water automatically.
3 - 220V 50HZ/110V 60HZ 4 - Plug can be selected for the specifications of your country.
5 - If you choose this, you do not need assistant tank.
Notice: 1) The angle of the frame can be changed in production as the local latitude condition of the customers.
We can design the suitable angle for the customers 2) We offer the spare accessories and tubes for your order for free 3) We can offer the different material of water tank, frame and tubes according to your request 4) We offer the fittings of this system, like immersion heater, water supplier, magnesium and so on.
You can buy according to your requirement.
Scope of Application: Non Pressurized Solar water heaters popular in Asia, Africa, torrid zone and warm area.
Company Contact:
- Phone: 86-135-11388384
- Address: YUANHUA, HAINING, ZHEJIANG, CHINA, HAINING , ZHEJIANG , China
- Email:
Published date: April 19, 2018
- Business Description: JIAXING PASSION NEW ENERGY TECHNOLOGY CO., LTD. is a manufacturer of Solar Water Heater since 1996.
As an experienced company, we can provide the perfect solution for Solar Thermal System.
Our products include solar water heater, solar collector and accessories.
