Portable Heat Pipe Collector 20 Tubes - China

Portable Flat Rooftop Sunny Energy Heat Pipe Solar Collector Installed on Flat or Pitched Roof Solar collector working principle: 1 - The heat pipe series solar collector are always connected with existing heating supply device.

2 - The selective coating on the inner Cover of the evacuated tubes converts solar energy into heat energy and transfers heat to the heat pipes by aluminum fins.

3 - The liquid in the heat pipe changes into vapour which rises to the condenser.

4 - The heat then passes through the heat exchanger and the vapour becomes liquid, returning to the base of the heat pipe.

5 - The heat conducts to the heat transfer liquid (anti-freezing liquid or water) via a copper pipe.

6 - This transference of heat into the liquid creates a continuous circulation as long as the collector is heated by the sun.

Solar collectors specification: 1 - Manifold (interior): 0.8mm thickness Red copper 2 - Manifold (exterior): 2.0mm thickness Aluminum alloy ( black or silver color ) 3 - Glass tube dimensions: 58mm x 1.800mm 4 - Insulation layer: 45mm thickness glass fiber /polyurethane layer 5 - Heat preservation: 72-96hrs 6 - Hail resistance: 25mm 7 - Max pressure: 6 bar 8 - Coating of vacuum tube: Cu/SS-ALN(H)/SS-ALN( L)/ALN 9 - Frame: 2.0mm thickness Aluminum Alloy ( black or silver color ) Solar collector Feature: 1 - That collector can install anywhere, space is unlimited.

on roof, or yard lawn.

2 - That product work with work station, make a full system completely automatic, you can use hot water anytime, high efficient, and no-pollution.

3 - Installation: install full system is very easy just connect each parts, each system have manual instruction.

4 - Use copper pipe for transfer hot, more high efficient, and water more clear, because no water in tube so can work in bad weather condition.

5 - Capacity suit with : 100-500L, special minds can designed like swimming pool heat system.

- - - - Heat Pipe Solar Collector Detailed Specification | Item | Parts | Description | Manifold box | Manifold Outer Case | 1001 Aluminum alloy with plastic spraying; thickness: 2.0mm; | Heat Insulation Layer | Rock wool, thickness: 55mm, density 120-140kg/m 3 | Copper Header Tube | TU2, thickness: 1.0 mm, Hole spacing: 75mm, max operation pressure 6 bar, phosphor copper brazing | End Cover | Nylon | Dust Ring | Silicone Rubber 110 | Tube holder | Nylon 66 | Frame | Frame | Aluminum alloy with plastic spraying; thickness: 2.0mm | Heat Pipe Evacuated Tube | Vacuum Tube | Three high vacuum tube, ALN/ALN-SS/CU absorber coating, Dia: 58mm, Length: 1800mm.

| Copper Heat Pipe | TU1, Silver Soldering; Condenser of the pipe: diameter: 14mm; length: 70mm; wall thickness: 1.0mm; The rest of the pipe: diameter: 8mm; length: 1700mm; wall thickness: 0.8mm | Aluminum Fin | AL; thickness: 0.2mm; Length: 1600mm | Tube Plug | Silicone Rubber and Stainless Steel | Model | Supply hot water(L) | Dia& Length of tube(mm) | Qty.

of tubes(pcs) | Absorber Area(sqm) | Loading of 20GP/40HQ | PT-SC-58-1800-10 | 100 | 58*1800 | 10 | 1.41 | 148/361 | PT-SC-58-1800-15 | 150 | 58*1800 | 15 | 2.10 | 138/336 | PT-SC-58-1800-18 | 180 | 58*1800 | 18 | 2.52 | 116/282 | PT-SC-58-1800-20 | 200 | 58*1800 | 20 | 2.80 | 95/237 | PT-SC-58-1800-25 | 250 | 58*1800 | 25 | 3.50 | 86/215 | PT-SC-58-1800-30 | 300 | 58*1800 | 30 | 4.20 | 61/152 | PT-SC-58-1800-36 | 360 | 58*1800 | 36 | 4.80 | 52/ 128 | - - - - Packaging & Delivery Packaging Details: 1 - Standard export packing for FCL order.

2 - Special packing for LCL order.

Delivery Detail: 10-15 days after receipt of deposit.

FAQ 1- What is your Delivery Time? LCL order/Sample order: 3--7days.

Full container order: 7-10days.

2- What is your Guarantee Time? 3 years.

3- Can you accept OEM ? YES, will do OEM Basing on all your detailed requirements.

4- What is your Payment Term? We accept T/T, Escrow & West Union 5-What is your MOQ? 1 set 6-What is your Packing? LCL order/Sample order in wooden box Package Full container order in Standard quality export carton with PE Foam Protection 7-What is your FOB Port? We accept FOB Shanghai & Ningbo 8-What is your Monthly Production Capacity? 1000 sets 9-What is your Shipping Term? By Sea/Air/Rail
