Split Pressurized Solar Water Heater 200l - China

200L High Absorption Blue Titanium Flat Plate Split Solar Water Heater Aluminium Full Plate for House Features Flat Solar Collector with pressure bearing function.

The important part is made of black chrome plating high quality brass processed by special technology after Ultrasonic welding.

The characteristic of this kind of solar collector is: high solar radiation heat absorption ratio, low emissivity, high pressure bearing ability (1 MPa ~1 - 5 MPa).

Depending on the climate characteristic of European countries and south part of China, strict design for leakage free structure has been applied.

The efficiency of whole set solar collector can reach no lower than 50%.

Working principles The collector absorbs solar energy and transmits it to the water tank through circulation.

When the temperature of the collector reaches the set value, the controller starts the circulation pump automatically.

The circulation pump makes heat-conducting liquid circulate automatically.

Then the heat-conducting liquid transfers heat to water by heat exchanger in the tank to heat the water.

Description Separated pressurized flat panel solar water heater is the biggest difference from past directly water cycle water heater that it adopt a specific kind of medium.

The medium flows through collector and absorbs a great deal of heat, then circulate to water tank and heat the water inside tank.

Due to the super heat radiating performance and the medium doesnt directly touch water flow, so the thermal efficiency it collect is very high.

Technical Data - - - - Germany technology split high pressure flat plate gravity-fed solar water heater | Model | PT-150 (1) | PT-200 (1) | PT-250 (2) | PT-300 (2) | PT-400 (3) | PT-500 (3) | | | | Solar Collector | Core Material | Copper | | Coating | Cooper cover coating of blue titanium which made in Germany Absorption rate: =0.95 Reflection rate =0.04 - | Water Tank | Volume | 150L | 200L | 250L | 300L | 400L | 500L | | | | | Insulating Layer | Polyurethane Foaming, Thickness: 45mm-50mm | | Outer Tank | Color Steel Plate(enamal white), Thickness: 0.53mm | | Inner tank | tank: stainless steel 304; Thickness: 1.2-1.5mm; Normal working pressure: 6 bar; Test pressure: 12 bar | Workstation | Circulation Pump | RS-15/6(WILO) | | Controller | SR868C8 | - - - - Service the pre-sale service 1 - Sample can be offered with sample charge and courier fee by buyer's side.

2 - We have full stock, and can deliver within short time.

Many styles for you to choose.

3 - OEM and ODM order are accepted, Any kind of logo printing or design are available.

4 - Good Quality + Factory Price + Quick Response + Reliable Service, is what we are trying best to offer you.

5 - All of our products are produced by our professional workman and we have our high-work-effect foreign trade team, you can totally believe our service.

6 - We have rich experience of design, manufacture and sell gypsum decoration, we cherish every order from our honor.

the on-sale service 1 - We will count cheapest shipping cost and make invoice to you at once.

2 - Check quality again, then send out to you at 1-2 working day after your payment, 3 - Email you the tracking no, and help to chase the parcels until it arrive you.

the after-sale service 1 - We are very glad that customer give us some suggestion for price and products.

2 - If any question, please contact with us freely by E-mail or Telephone.

Our employee will be on the earliest time to help you solve the problem.

Company Contact:

• Posted By: JIAXING PASSION NEW ENERGY TECHNOLOGY CO., LTD.

• Phone: 86-135-11388384

• Address: YUANHUA, HAINING, ZHEJIANG, CHINA, HAINING , ZHEJIANG , China

• Email:

• Website: https://www.thermalsolarwaterheater.com

• Business Description: JIAXING PASSION NEW ENERGY TECHNOLOGY CO., LTD. is a manufacturer of Solar Water Heater since 1996.

  As an experienced company, we can provide the perfect solution for Solar Thermal System.

  Our products include solar water heater, solar collector and accessories.
