Vacuum Tube Thermal Solar Collector For Swimming Pool - China

50tubes All Stainless Steel High Efficiency Vacuum Tube Thermal Solar Collector for Swimming Pool Specifications Non pressure solar collector CE, ISO, SRCC approved 24 hours automatic water supply Indirect run, clean Non pressure solar collector -House Hold Hot Water -Car washing/Industrial -Camping/Camps/Cottage -Underground Floor Heating Advantages Cheap and reliable warming solution with simple structure and easy installation Could be used in any climate High efficiency with daily average efficiency higher than 80-85% Withstands full main pressure of household water supply Operation without any power supply when using solar water circulation pumps Could be installed with parallel and/or series connections Auxiliary electric booster is optional: 1500W Components - Solar Collector - Vacuum Tubes - Solar Vacuum Tube - Smart Controller - Water Storage Tank Working Principle of Solar collector 1 - The solar collector connect with non-pressurized solar tank.

2 - The water pass through solar manifold then into vacuum tube, vacuum tube absorb solar energy, heating the water inside of vacuum tube.

3 - According to density difference, the cold water through down into vacuum tube, and hot water flow up into solar manifold, then storage in heat protection water tank.

4 - After circulation by temperature circulation pump, all of the cold water will be heated to hot water and storaged in heat protection water tank.

Technical Data: - - - - Vacuum Tube | Size (mm) | 58*1800 / 47*1500 | Tube (pcs) | 40 / 50 / 60 / 70 | Glass | Double layer borosilicate 3.3 glass with high vacuum | Coating | Single-target AL/AL-ALN(H) or three-target Cu/SS-ALN | Manifold | Shape | Rectangular / Round | Manifold tank | Food-grade stainless steel SUS304-2B / SUS316 | Manifold shell | Color steel gray painted | Insulation | High-density polyurethane foaming 40MM thickness | Bracket | Shaped strong aluminum alloy structure adaptable to flat or slope roof | Accessories | Anti-aging silicon seals, dust proof seals, stainless screws | Connection | 1 inch male thread (larger size is available) | Collector Angle | 5 ~ 90 | Hail Resistance | 25 mm diameter | Model Number | Solar Vacuum Tube | Aperture Area/ m2 | Container Loading Qty /sets | Size /mm | Qty /pcs | 20GP | 40GP | 40HQ | PT-5818CA-40 | 58*1800 | 40 | 3.77 | 42 | 88 | 107 | PT-5818CA-50 | 50 | 4.71 | 34 | 70 | 86 | PT-5818CA-60 | 60 | 5.66 | 28 | 58 | 71 | - - - - Warranty 5 years international responsibility for vacuum tube solar collector and 15 years for glass vacuum tubes due to original quality problems.

FAQ Model selection: Usually we suggest 58*1800MM tube solar collector which is more cost effective.

Technical support: offers design and installation instruction for customers with our 10 years installation experience.

OEM: Your LOGO information can be made on our Manifold Vacuum Tube Solar Collector and carton boxes.

ODM: Design manufacturing is available for manifold size and shape, tube length, frame structure, etc.

Company Contact:

• Posted By: JIAXING PASSION NEW ENERGY TECHNOLOGY CO., LTD.

• Phone: 86-135-11388384

• Address: YUANHUA, HAINING, ZHEJIANG, CHINA, HAINING , ZHEJIANG , China

• Email:

• Website: https://www.thermalsolarwaterheater.com

• Business Description: JIAXING PASSION NEW ENERGY TECHNOLOGY CO., LTD. is a manufacturer of Solar Water Heater since 1996.

  As an experienced company, we can provide the perfect solution for Solar Thermal System.

  Our products include solar water heater, solar collector and accessories.
