Shangchai Engine 4htaa4 3 G32 50kw 63kva Diesel Generator Set - China
price: 5000.00 Dollar US$
50KW 63KVA Diesel Generator Set Specifications
Genset model DB-50GF
Prime power 50kW 63kVA
Standby power 55KW 78kVA
Rated voltage(V) 400/230 (customizable)
Rate current(A) 90A
Power factor 0.8
Frequency(Hz) 50
Speed(rpm) 1500
Phase: 3 phase 4 wire
Noise level: 105dB at 7m ( open type diesel genset)
75dB at 7m(silent type diesel genset) Engine Specification Manufacturer Shangchai
Model 4HTAA4.3-G32
Engine output-prime 62kW
Engine output-standby 68kW
Frequency: 50Hz
Speed: 1500rpm
Cylinders no.
& Type: 4 cylinders, Inline, 4 stroke, diesel engine, water-cooled
Aspiration: Turbocharged Aftercooled
Bore*stroke 105*124mm
Displacement 4.3L
Compression Ratio 16: 1
Governor Electronic speed governor
Starter motor voltage: 24V DC
Type Injection System: direct injection
Oil Capacity 13L-11L
Cooling way Water Radiator & fan
Engine Coolant capacity 6.8L
Company Contact:
- Phone: +86 771 5805 269
- Address: No.10, Kechuang Road, GaoXin District, Nanning , Guangxi , China
- Email:
- Website: https://www.dbdieselgenerator.com/
Published date: September 27, 2024
- Business Description: Guangxi Dingbo Generator Set Manufacturing Co., Ltd., founded in 2006 in Guangxi, China, is a manufacturer providing power solutions.
We integrate the design, supply, commissioning and maintenance of diesel generator sets.
We offer diesel generators of all sizes and types from reputable brands like Cummins, Perkins, Volvo, Yuchai, Shangchai, Weichai, Ricardo, MTU, Wuxi power etc.
Dingbo Power caters to diverse power needs.
