Ups 2000w Dc Ac Power Inverter With 20a Charger Qw M2000ups - China

1 - Technical Parameter:

Input: Input voltage: DC12V/DC24V/DC48V

Working Voltage: DC10V-15V/DC20V-30V/DC40V -60V

Input current: 166A/83A/41A

Standby input power: <25W

Start no load current: <1A

Output: Rated power: 2000W

Peak power: 4000W

Efficiency: >85%

Output voltage: AC110V/220V+/-5%

Output frequency: 50/60Hz+/-1%

Output current: 18A/9A

Output waveform: Modified Sine Wave

UPS Charging function: Charging current: 10-15A/5-10A/ 2-5A

Input AC charging voltage: 180V-240V

Charging output no-load voltage: DC14.2V-14.5V/DC27.5V-28 - 5V/DC55.0V-56.5V

Charging output power: 100W-150W

Charging plug type: European plug

Charging way: 4 stages: pre-charge, man-charge, float-charge and full charge

Output mode: Mains preferred

Switch time: ≤10ms

Protection: Reverse connection protection: fuses burne

Low input voltage alarm: 10.1V+/-0.3V; 20.5V+/-0.3V; 42V+/-1V

Low input voltage protection: 10.7+/-0.3V; 20.1+/-0.3V; 40+/-2V

High Input voltage protecton: 15V+/-1V; 30V+/-1V; 60V+/-2V

High temperature protection: ≥70ºC

Over load protection: >2200W

Short circuit protection

Digital display Indicator:

Inverter woking: green light on

Inverter problem: no 110V/220v display

Charging indicator: digital of voltage up slowly

Charging process indicator: digital display charging voltage

Turn off the switch when charging which charging battery faster

Protection alarm:

Low input voltage alarm: buzzer

Low input voltage protection: no display, buzzer and inverter stop working

High input voltage protection: no output voltage display, have input display, inverter stop working.

Over load protection: voltage drop to 55V-140V

Abnormal temperature: no AC display, buzzer and stop working.

Environment: High temperature protectioin: ≥70ºC

Working Temperature: -10ºC~40ºC

Cooling mode: Intelligent Temperature control Fan

Package included: 1* QW-M2000UPS (280*170*135mm/6.5kg)

1* battery clamp

1* spare part

1* english user manual

1* standard packing box

2 - All protection:

1: High voltage protection

2: Low voltage protection

3: Over load protection

4: Over temperatuer protection

5: Overcurrent protection

6: Output short-circuit protection

7 - Reverse connection protection

8 - Internal fuse protection

9 - Buzzer alarm function

3 - Application:

Wind generation, solar panel, home, office, car, board and some place that lack electricity.

Ideally suitable for Journeys, Camping, Tents, Boat Trip, Working on the way and everywhere, where is no electricity!
