Glass Laminated Pet Solar Panel 10w - China

GEP10-P

Solar cell : Polycrystalline silicon solar cell 156×156mm

No.

of cells and connections: 36=2×18 pcs

Dimension of module : 330x250x18mm

Maximum power(Pm): 10 W

Voltage at max power(Vmp): 18V

Current at max power(Imp): 0.55A

Short circuit current(Isc): 0.6A

Open circuit voltage(Voc): 21.6V

Weight: with anodized aluminum alloy frame is 0.57KG.

whitout anodized aluminum alloy frame is 0.42KG

Operate Temp.

Scope: -20°C--+65°C

Relative Humidity: 0--100%

Test Conditions: 40000lux±1000lux, 25°C

Wind resistance: 60m/s

Pressure resistance: 200kg/m.

Materials

Glass

1 - High light transmission no less than 91.6%

2 - Excellent mechanical loading performance (5400 PA)

EVA

1 - High light transmission

2 - High GEL and peeling strength guarantying strong encapsulation

3 - Good ultraviolet aging resistance

4 - Excellent oxidation resistance

Cell

1 - Excellent efficiency and long term reliability

2 - Good performance under high temperature and low irradiate conditions

3.100% In-line Electro-luminescence (EL) tested100%

4 - Positive tolerance for each panel

5 - Cell efficiency filling by 0.2 percentage

Back sheet

1 - TPT based encapsulation and protection

2 - Good aging resistance

3 - Excellent adhesion and ultraviolet stability

Frame

1 - Anodized/ Electrophoretic aluminum means durable protection from environment

2 - Unique design profile ensuring strong mechanical loading performance

3 - Silver/ Black color available

Junction box

1 - Climate membrane: Excellent heat dissipation, prevent steam coming from outside and corrosion of diode by inside steam on the condition of big difference in temperature

2 - IP65 protection

Connector

1 - MC4 compatible/ IP65

2 - MC4 original/ IP67
