Chemical Industry Stainless Steel Woven Wire Mesh Screen 304hps 316l Material - China

Precision Ultra Finer Chemical Industry Stainless Steel Screen Printing Mesh Plain Weave Descriptionof the Steel Screen Printing Mesh : By selecting specially alloy materials and using advanced weaving technology, the structure of the stainless steel printing network is more compact, and the tolerance within the tolerance range is guaranteed.

Openings can be square, rectangular or special openings.

Generally speaking, this kind of wire mesh has standard opening size, uniform opening, good permeability and high strength.

Raw materials should be selected according to different application environment.

- - - - Material | 304HPS, 316L | Weave | Plain weave | Features | Non-electrostatic | Aperture size | 41-268micron | wire diameter | 0.018-0.02mm | - - - - Featuersof the Steel Screen Printing Mesh : High tension.

Much higher tension than common polyester mesh, and this property is very stable.

Low Elongation: Very small elongation of wire mesh at igh tension.

High-Flexibility: The wire mesh will not lose elasticity at extremely tension.

High-Corrosion Resistance: The excellent corrosion resistance of stainless steel wire exceeds polyester fiber.

Non-electrostatic: To avoid affects of nonelectrostatic for printing and ensure the safety of printing.

Good Solvent Resistance: To avoid the affects of any solvents to wire mesh and to ensure the safety of printing.

Specification of the Steel Screen Printing Mesh : - - - - Specification | Mesh/inch | Wire Dia (mm) | Open area Ratio(%) | Apereture (mm) | Thickness(mm) | Calendered Thickness (mm) | Theoretical lnk(cm^/m^) | 40*40*0.16 | 40 | 0.16 | 56.0 | 0.475 | 0.3-0.32 | As order | 179.1 | 60*60*0.12 | 60 | 0.12 | 51.3 | 0.303 | 0.23-0.245 | As order | 123.2 | 80*80*0.12 | 80 | 0.12 | 39.0 | 0.198 | 0.235-0.245 | As order | 92.9 | 80*80*0.09 | 80 | 0.09 | 52.0 | 0.228 | 0.175-0.18 | As order | 103.0 | 80*80*0.05 | 80 | 0.05 | 71.0 | 0.268 | 0.095-0.1 | As order | 78.0 | 100*100*0.1 | 100 | 0.1 | 36.8 | 0.154 | 0.195-0.205 | As order | 77.2 | 120*120*0.08 | 120 | 0.08 | 39.0 | 0.132 | 0.155-0.165 | As order | 65.8 | 150*150*0.06 | 150 | 0.06 | 41.7 | 0.109 | 0.115-0.124 | As order | 50.0 | 165*165*0.035 | 165 | 0.035 | 60.0 | 0.119 | 0.07-0.075 | As order | 48.0 | - - - - Application of the Steel Screen Printing Mesh : Solar battery, Pinted Circuit Board(PCB), Chip Electrical components, Flat Panel Display, Liquid Crystal Display(LCD), Plasma Display Panel(PDP) ECT.
