H05v K 450 750v Armored Electrical Wire Bs6004 Flexible For Internal Connectors - China
price: check with company for price
H05V-K PVC Electrical Cable 450-750V According to BS6004 Flexible Wire Application European Harmonised Standard H05V-K and H07V-K, is primarily used as flexible panel wire and is available in a wide range of different colours for this purpose.
Designed for internal equipment wiring in switch control, relay and instrumentation panels of power switchgear, and for purposes such as internal connectors in rectifier equipment, motor starters and controllers, this flexible cable can be installed in open air, in conduits, or in trunking.
CHARACTERISTICS Voltage Rating (Uo/U) H05V-K: 300/500V H07V-K: 450/750V Temperature Rating Fixed: -30C to +70C Flexed: -5C to +70C Minimum Bending Radius D<10 mm for 3D 10-25 mm for 4D D>25 mm for 5D Dimensions H05V-K - - - - Unique PART NO.
| NOMINAL CROSS SECTIONAL AREA mm | NOMINAL OVERALL DIAMETER mm | NOMINAL WEIGHT kg/km | UNH05V-K0.5 | 0.5 | 2.2 | 9 | UNH05V-K0.75 | 0.8 | 2.4 | 11 | UNH05V-K1.0 | 1.0 | 2.5 | 14 | - - - - H07V-K - - - - Unique PART NO.
| NOMINAL CROSS SECTIONAL AREA mm | NOMINAL OVERALL DIAMETER mm | NOMINAL WEIGHT kg/km | H07V-K1.5 | 1.5 | 2.9 | 20 | H07V-K2.5 | 2.5 | 3.6 | 31 | H07V-K4 | 4 | 4.1 | 46 | H07V-K6 | 6 | 4.7 | 75 | H07V-K10 | 10 | 6.1 | 125 | H07V-K16 | 16 | 7.3 | 199 | H07V-K25 | 25 | 9 | 299 | H07V-K35 | 35 | 10.2 | 421 | H07V-K50 | 50 | 12.1 | 539 | H07V-K70 | 70 | 13.8 | 730 | H07V-K95 | 95 | 16.3 | 973 | - - - - Color Code - - - - COLOUR | Black | Blue | Grey | Green/ Yellow | Orange | Red | Pink | Yellow | Violet | Brown | White | CODE | BK | BL | GR | GY | OR | RD | PK | YW | VI | BR | WH | - - - - CONDUCTORS Class 5 Flexible Copper Conductors for Single Core and Multi-Core Cables - - - - NOMINAL CROSS SECTIONAL AREA | MAXIMUM DIAMETER OF WIRES IN CONDUCTOR | MAXIMUM RESISTANCE OF CONDUCTOR AT 20C | Plain Wires | Metal-Coated Wires | mm | mm | ohms/km | ohms/km | 0.5 | 0.21 | 39 | 40.1 | 0.75 | 0.21 | 26 | 26.7 | 1 | 0.21 | 19.5 | 20 | 1.5 | 0.26 | 13.3 | 13.7 | 2.5 | 0.26 | 7.98 | 8.21 | 4 | 0.31 | 4.95 | 5.09 | 6 | 0.31 | 3.3 | 3.39 | 10 | 0.41 | 1.91 | 1.95 | 16 | 0.41 | 1.21 | 1.24 | 25 | 0.41 | 0.78 | 0.795 | 35 | 0.41 | 0.554 | 0.565 | 50 | 0.41 | 0.386 | 0.393 | 70 | 0.51 | 0.272 | 0.277 | 95 | 0.51 | 0.206 | 0.21 | - - - - ELECTRICAL CHARACTERISTICS Current Carrying Capacity - - - - NOMINAL CROSS SECTIONAL AREA | IN A THERMAL INSULATED WALL | ON A WALL | IN FREE AIR | mm | 2 Core Amps | 3 Core Amps | 2 Core Amps | 3 Core Amps | 1 Core Amps | 0.5 | - | - | - | - | - | 0.75 | - | - | - | - | 15 | 1 | - | - | - | - | 19 | 1.5 | 14.5 | 13.5 | 17.5 | 15.5 | 24 | 2.5 | 19.5 | 18 | 24 | 21 | 32 | 4 | 26 | 24 | 32 | 28 | 42 | 6 | 34 | 31 | 41 | 36 | 54 | 10 | 46 | 42 | 57 | 50 | 73 | 16 | 61 | 56 | 76 | 68 | 98 | 25 | 80 | 73 | 101 | 89 | 129 | 35 | 99 | 89 | 125 | 110 | 158 | 50 | 119 | 108 | 151 | 134 | 198 | 70 | 151 | 136 | 192 | 171 | 245 | 95 | 182 | 164 | 232 | 207 | 292 | - - - -
Company Contact:
- Phone: 86-27-82757025
- Address: Room B813,No.61, Yejin Avenue, Qingshan District,Wuhan City, Hubei Province, China, Wuhan , Hubei , China
- Email:
Published date: March 20, 2018
- Business Description: UNI-CABLES, Brand owned by a group company of WUMEE, which now has four factories in China.
Wuhan Unique Electric Wire and Cable Co., Ltd, Guangdong Unique Cable Co., Ltd, Guangxi Unique Aluminum Co., Ltd, Wuhan Unique No.
2 Factory.
