Insulated Sheathed Bs 6004 Pvc Electrical Cable Industrial Polyvinyl Chloride 6181y - China

price: check with company for price

Insulated Sheathed Bs 6004 Pvc Electrical Cable Industrial Polyvinyl Chloride 6181y

Products Photos Catalog Insulated Sheathed Photos Catalog

BS 6004 Cable Fixed Wiring Cable Type 6181Y PVC Insulated and Sheathed Cable APPLICATION Fixed installation in dry or damp areas for domestic and lightindustrial wiring.

Also used in connection to (smart)meters.

BS EN 50525-3-41 (previously BS 7211) DIMENSIONS - - - - NOMINAL CROSS SECTIONAL AREA mm | NOMINAL DIAMETER OF CONDUCTOR mm | NOMINAL THICKNESS OF INSULATION mm | NOMINAL OVERALL DIAMETER mm | NOMINAL WEIGHT kg/km | 1 | 1.13 | 0.6 | 4.1 | 28 | 1.5 | 1.38 | 0.7 | 4.6 | 34 | 2.5 | 1.76 | 0.8 | 5.3 | 49 | 4 | 2.5 | 0.8 | 6.1 | 75 | 6 | 3 | 0.8 | 6.7 | 99 | 10 | 3.85 | 1 | 8.1 | 155 | 16 | 4.8 | 1 | 9.3 | 225 | 25 | 5.9 | 1.2 | 11.1 | 340 | - - - - Colour Codes - - - - COLOUR | Blue | Brown | CODE | BL | BR | - - - - CONDUCTORS Class 1 Stranded Conductors for Single Core and Multi-Core Cables - - - - NOMINAL CROSS SECTIONAL AREA mm | MAXIMUM RESISTANCE OF CONDUCTOR AT 20C | Circular, Annealed Copper Conductors | Plain Wires ohms/km | Metal-Coated Wires ohms/km | 1 | 18.1 | 18.2 | 1.5 | 12.1 | 12.2 | 2.5 | 7.41 | 7.56 | - - - - Class 2 Stranded Conductors for Single Core and Multi-Core Cables - - - - NOMINAL CROSS SECTIONAL AREA mm | NOMINAL CROSS SECTIONAL AREA mm | MAXIMUM RESISTANCE OF CONDUCTOR AT 20C | Circular | Circular Compacted | Shaped | Annealed Copper Conductor | Cu | Al | Cu | Al | Cu | Al | Plain Wires ohms/km | Metal-Coated Wires ohms/km | 4 | 7 | - | 6 | - | - | - | 4.61 | 4.7 | 6 | 7 | - | 6 | - | - | - | 3.08 | 3.11 | 10 | 7 | 7 | 6 | 6 | - | - | 1.83 | 1.84 | 16 | 7 | 7 | 6 | 6 | - | - | 1.15 | 1.16 | 25 | 7 | 7 | 6 | 6 | 6 | 6 | 0.727 | 0.734 | - - - -


Company Contact:


  • Phone: 86-27-82757025

  • Address: Room B813,No.61, Yejin Avenue, Qingshan District,Wuhan City, Hubei Province, China, Wuhan , Hubei , China

  • Email: Email


Published date: March 20, 2018

  • Business Description: UNI-CABLES, Brand owned by a group company of WUMEE, which now has four factories in China.

    Wuhan Unique Electric Wire and Cable Co., Ltd, Guangdong Unique Cable Co., Ltd, Guangxi Unique Aluminum Co., Ltd, Wuhan Unique No.

    2 Factory.
