Light Blue Pvc Tri Rated Wire Rectifier Equipment Flame Retardant Cable - China
price: check with company for price
Tri-Rated Wire PVC Electrical Cable H05V2-K / H07V2-K / BS 6231 UL1015 APPLICATION High temperature, flame retardant cable designed for use inthe switch control, relay and instrumentation panels of powerswitchgear and for purposes such as internal connectors inrectifier equipment, motor starters and controllers.
Tri-ratedcable is sometimes referred to as BS 6231 cable, H07V2-Kor panel wire.
CABLE STANDARDS BS EN 50525-2-31* BS 6231 Type CK, UL Subj.
758, CSA C22.2 No.
210 (HD 21.7 S2) #LL246095, BS EN/IEC 60332, BS EN 60228 CHARACTERISTICS Voltage Rating (Uo/U) UL, CSA: 600/1000V BS 6231: 600/1000V BS EN 50525-2-31: 300/500V, 450/750V Temperature Rating UL, CSA: +105C BS 6231: +90C Minimum: -15C Minimum Bending Radius 6 x overall diameter Sheath Colour Red Black Blue Light Blue Dark Blue Yellow Green/Yellow Grey Brown Orange White Violet Green Pink DIMENSIONS - - - - NO.
OF CORES | NOMINAL CROSS SECTIONAL AREA | APPROXIMATE AWG | NOMINAL THICKNESS OF INSULATION | NOMINAL OVERALL DIAMETER | NOMINAL WEIGHT | mm | mm | mm | kg/km | 1 | 0.5 | 21 | 0.8 | 2.7 | 11 | 1 | 0.75 | 19 | 0.8 | 2.85 | 15 | 1 | 1 | 18 | 0.8 | 3 | 18 | 1 | 1.5 | 16 | 0.8 | 3.3 | 23 | 1 | 2.5 | 14 | 0.8 | 3.75 | 35 | 1 | 4 | 12 | 0.8 | 4.35 | 48 | 1 | 6 | 10 | 0.8 | 4.85 | 69 | 1 | 10 | 8 | 1 | 6.3 | 117 | 1 | 16 | 6 | 1 | 8.1 | 191 | 1 | 25 | 4 | 1.2 | 9.4 | 281 | 1 | 35 | 2 | 1.2 | 10.9 | 389 | 1 | 50 | 1 | 1.4 | 13.1 | 560 | 1 | 70 | 2/0 | 1.4 | 15.1 | 774 | 1 | 95 | 3/0 | 1.6 | 16.1 | 991 | 1 | 120 | 4/0 | 1.6 | 17.9 | 1231 | 1 | 150 | 250 MCM | 1.8 | 20.2 | 1534 | 1 | 185 | 350 MCM | 2 | 22.85 | 1878 | 1 | 240 | 450 MCM | 2.2 | 24.4 | 2381 | - - - - Colour Codes - - - - COLOUR | Black | Green | Blue | Light Blue | Dark Blue | Grey | Green/ Yellow | Orange | Red | Pink | Yellow | Violet | Brown | White | CODE | BK | GN | BL | LTBL | DKBL | GR | GY | OR | RD | PK | YW | VI | BR | WH | - - - - CONDUCTORS Class 5 Flexible Copper Conductors for Single Core and Multi-Core Cables - - - - NOMINAL CROSS SECTIONAL AREA | MAXIMUM DIAMETER OF WIRES IN CONDUCTOR | MAXIMUM RESISTANCE OF CONDUCTOR AT 20C | mm | mm | Plain Wires ohms/km | 0.5 | 0.21 | 39 | 0.75 | 0.21 | 26 | 1 | 0.21 | 19.5 | 1.5 | 0.26 | 13.3 | 2.5 | 0.26 | 7.98 | 4 | 0.31 | 4.95 | 6 | 0.31 | 3.3 | 10 | 0.41 | 1.91 | 16 | 0.41 | 1.21 | 25 | 0.41 | 0.78 | 35 | 0.41 | 0.554 | 50 | 0.41 | 0.386 | 70 | 0.51 | 0.272 | 95 | 0.51 | 0.206 | 120 | 0.51 | 0.161 | 150 | 0.51 | 0.129 | 185 | 0.51 | 0.106 | 240 | 0.51 | 0.0801 | - - - - ELECTRICAL CHARACTERISTICS Current Carrying Capacity and Voltage Drop - - - - NOMINAL CROSS SECTIONAL AREA mm | CURRENT RATING (PEAK) Amps | VOLTAGE DROP mV/A/m | 0.5 | 11 | 46 | 0.75 | 14 | 31 | 1 | 17 | 22 | 1.5 | 21 | 15 | 2.5 | 30 | 9.1 | 4 | 41 | 5.7 | 6 | 53 | 3.8 | 10 | 75 | 2.2 | 16 | 100 | 1.4 | 25 | 136 | 0.89 | 35 | 167 | 0.64 | 50 | 204 | 0.45 | 70 | 259 | 0.32 | 95 | 321 | 0.24 | 120 | 374 | 0.19 | 150 | 429 | 0.16 | 185 | 496 | 0.13 | 240 | 595 | 0.1 | - - - -
Company Contact:
- Phone: 86-27-82757025
- Address: Room B813,No.61, Yejin Avenue, Qingshan District,Wuhan City, Hubei Province, China, Wuhan , Hubei , China
- Email:
Published date: March 20, 2018
- Business Description: UNI-CABLES, Brand owned by a group company of WUMEE, which now has four factories in China.
Wuhan Unique Electric Wire and Cable Co., Ltd, Guangdong Unique Cable Co., Ltd, Guangxi Unique Aluminum Co., Ltd, Wuhan Unique No.
2 Factory.
