Ul Standard Flexible Armored Cable Connection Electronic Polyvinyl Chloride Wire - China

price: check with company for price

Ul Standard Flexible Armored Cable Connection Electronic Polyvinyl Chloride Wire

Products Photos Catalog Flexible Armored Cable Photos Catalog

600V Hook Up Wire PVC Electrical Cable UL Standard Internal Connection Wire APPLICATION For general purpose internal wiring of electronic and electricalequipment, where exposed to oil at a temperature not exceeding60C or 80C.

Uniform insulation thickness of wire to ensureeasy stripping and cutting.

Resistant to acids, alkalis, oils, moisture and fungi.

CABLE STANDARDS UL 758, UL 1581, CSA C22-2, UL VW-1, CSA FT1 DIMENSIONS - - - - Size | COND.

TYPE | CONDUCTOR | INSULATION | MAX RESISTANCE AT 20C | MIN.

INSULATION RESISTANCE AT 20C ohms/km | DIELECTRIC STRENGHT AC 1MIN V | SPEC AWG | NO.

mm | NOMINAL DIAMETER mm | NOMINAL THICKNESS mm | OVERALL DIAMETER mm | 30AWG | Stranded Conductor | 30 | 7/0.1 | 0.3 | 0.79 | 1.880.1 | 354.24 | 15 | 1500 | 28AWG | 28 | 7/0.127 | 0.38 | 0.79 | 1.960.1 | 223.75 | 26AWG | 26 | 7/0.16 | 0.48 | 0.79 | 2.060.1 | 136.73 | 24AWG | 24 | 11/0.16 | 0.61 | 0.79 | 2.190.1 | 93.3 | 22AWG | 22 | 17/0.16 | 0.76 | 0.79 | 2.340.1 | 55 | 20AWG | 20 | 26/0.16 | 0.94 | 0.79 | 2.520.1 | 34.6 | 18AWG | 18 | 41/0.16 | 1.18 | 0.79 | 2.760.1 | 21.8 | 16AWG | 16 | 26/0.254 | 1.49 | 0.79 | 3.070.1 | 13.7 | 14AWG | 14 | 41/0.254 | 1.88 | 0.79 | 3.460.1 | 8.62 | 12AWG | 12 | 65/0.254 | 2.37 | 0.79 | 3.950.1 | 5.43 | 10AWG | 10 | 105/0.254 | 3.4 | 0.79 | 4.980.1 | 3.41 | 10AWG | 10 | 49/0.37 | 3.38 | 0.79 | 4.960.1 | 3.41 | 8AWG | 8 | 168/0.254 | 4.3 | 1.15 | 6.60.2 | 2.16 | 6AWG | 6 | 266/0.254 | 5.46 | 1.52 | 8.50.2 | 1.39 | 28AWG | Solid Conductor | 28 | 1/0.32 | 0.32 | 0.79 | 1.90.1 | 227.39 | 15 | 1500 | 26AWG | 26 | 1/0.404 | 0.404 | 0.79 | 1.980.1 | 142.79 | 24AWG | 24 | 1/0.511 | 0.511 | 0.79 | 2.090.1 | 89.39 | 22AWG | 22 | 1/0.813 | 0.643 | 0.79 | 2.220.1 | 54.3 | 20AWG | 20 | 1/1.29 | 0.813 | 0.79 | 2.390.1 | 33.9 | 18AWG | 18 | 1/1.024 | 1.024 | 0.79 | 2.60.1 | 21.4 | 16AWG | 16 | 1/1.29 | 1.29 | 0.79 | 2.870.1 | 13.5 | - - - - UL Listed.


Company Contact:


  • Phone: 86-27-82757025

  • Address: Room B813,No.61, Yejin Avenue, Qingshan District,Wuhan City, Hubei Province, China, Wuhan , Hubei , China

  • Email: Email


Published date: March 20, 2018

  • Business Description: UNI-CABLES, Brand owned by a group company of WUMEE, which now has four factories in China.

    Wuhan Unique Electric Wire and Cable Co., Ltd, Guangdong Unique Cable Co., Ltd, Guangxi Unique Aluminum Co., Ltd, Wuhan Unique No.

    2 Factory.
