Xhhw 2 Entrance Underground Service Cable Ul Listed Aa8030 Conductor - China

price: check with company for price

Xhhw 2 Entrance Underground Service Cable Ul Listed Aa8030 Conductor

Products Photos Catalog Xhhw Entrance Photos Catalog

UL Listed XHHW-2 Cable Service Entrance Cable AA8030 Conductor Service Cable APPLICATIONS XHHW-2 conductors are primarily used in conduit or recognized raceways for services, feeders, and branch circuit wiring as specified in the National Electrical Code.

XHHW-2 conductors may be used in wet or dry locations at temperatures not to exceed 90C.

Voltage rating for XHHW-2 conductors is 600 volts.

Suitable for use in Health Care Facilities per section 517.160 of the NEC where a dielectric constant of 3.5 or less may be specified.

This product in sizes 500kcmil and larger is designed to be installed without the application of pulling lubricant.

Mian Feature # 600 Volt.

Aluminum Alloy (AA-8030) Conductor.

# Cross-linked Polyethylene (XLP) Insulation.

# High-Heat and Moisture Resistant.

# Sunlight Resistant in Black Sizes 2 AWG and Larger.

DIMENSIONS - - - - UNI-CABLES Part Number | Size AWG | Stranding | Conductor Diameter (inches) | Insulation Thickness (inches) | Overall Diameter (inches) | Weight LBS/1000' | Ampacity at 90C * | AL-XHHW-8 | 8 | 7 | 0.134 | 0.045 | 0.227 | 30 | 45 | AL-XHHW-6 | 6 | 7 | 0.169 | 0.045 | 0.262 | 42 | 60 | AL-XHHW-4 | 4 | 7 | 0.213 | 0.045 | 0.306 | 68 | 75 | AL-XHHW-2 | 2 | 7 | 0.268 | 0.045 | 0.361 | 86 | 100 | AL-XHHW-1 | 1 | 7 | 0.299 | 0.550 | 0.412 | 110 | 115 | AL-XHHW-1/0 | 1/0 | 18 | 0.335 | 0.550 | 0.449 | 134 | 135 | AL-XHHW-2/0 | 2/0 | 18 | 0.378 | 0.550 | 0.489 | 163 | 150 | AL-XHHW-3/0 | 3/0 | 18 | 0.423 | 0.550 | 0.536 | 200 | 175 | AL-XHHW-4/0 | 4/0 | 18 | 0.476 | 0.550 | 0.588 | 247 | 205 | AL-XHHW-250 | 250 | 35 | 0.520 | 0.650 | 0.653 | 296 | 230 | AL-XHHW-300 | 300 | 35 | 0.571 | 0.650 | 0.703 | 359 | 255 | AL-XHHW-350 | 350 | 35 | 0.614 | 0.650 | 0.749 | 401 | 280 | AL-XHHW-400 | 400 | 35 | 0.657 | 0.650 | 0.792 | 453 | 305 | AL-XHHW-500 | 500 | 35 | 0.736 | 0.650 | 0.869 | 556 | 350 | AL-XHHW-600 | 600 | 58 | 0.816 | 0.800 | 0.979 | 679 | 385 | AL-XHHW-700 | 700 | 58 | 0.877 | 0.800 | 1.040 | 782 | 420 | AL-XHHW-750 | 750 | 58 | 0.909 | 0.800 | 1.071 | 833 | 435 | AL-XHHW-900 | 900 | 58 | 0.999 | 0.800 | 1.162 | 987 | 480 | AL-XHHW-1000 | 1000 | 58 | 1.059 | 0.800 | 1.223 | 1090 | 500 | - - - -


Company Contact:


  • Phone: 86-27-82757025

  • Address: Room B813,No.61, Yejin Avenue, Qingshan District,Wuhan City, Hubei Province, China, Wuhan , Hubei , China

  • Email: Email


Published date: March 20, 2018

  • Business Description: UNI-CABLES, Brand owned by a group company of WUMEE, which now has four factories in China.

    Wuhan Unique Electric Wire and Cable Co., Ltd, Guangdong Unique Cable Co., Ltd, Guangxi Unique Aluminum Co., Ltd, Wuhan Unique No.

    2 Factory.
