Flexible Stainless Steel Braided Teflon Air Hose To Nigeria - China

Contact information

Sales Manager: lurywen

Mobile Phone: +86-13323183257

Tel: 86-318-5106277

Fax: 86-0318-5106277

Company: Hengshui Jianfeng Engineering Rubber co., LTD. Application: High Pressure rotary service in drilling and exploration work.

Lengths: 30' 35' 40' 45' 50' 55' 60' 65' 70' 75'.

Also available in any length from 5ft to 90ft.

Tube: Black, oil and abrasion resistant NBR.

Suitable for oil or water based mud.

Protective breaker fabric over tube improves adhesion to body plies.

Reinforcement: Multiple plies of high tensile wire

Cover: Black, oil, weather and abrasion resistant Neoprene (CR)

Temperature: -4 to 200F

Fitting: Full-flow leak proof couplings that are integrally secured to hose reinforcement.

Supplied with male API threaded ends.

Can be supplied with flanges, unions, swivels and other types of couplings on request.

Product usage

Each type of fabric delivery (or appeal) hose is according to different medium to select corresponding materials, the structure design of product is reasonable, good quality, durable, is one is to lose, vacuum (negative pressure condition) of various liquid viscous fluid and solid material medium flexible hose.

According to the purpose can be divided into:

1, Water hose: suitable for general water, used in the environment about 2, Air hose: suitable for conveying compressed air and inert gas, used in the environment about 3, Oil resistant rubber hose: suitable for conveying conventional oil, used in the environment about

-20 ºC ~ 45 ºC .

4, Heat resistant rubber hose: suitable for conveying the water below 100 ºC.

5, Dilute acid and alkali resistant rubber hose: flow of dilute alkali solution concentration below 40%, used in the environment about

6, Sand blasting hose: suitable for metal surface polished.

7, Suction drainage, oil hose: work pressure 1.0 -1.5 MPa(4 times safety factor).

8, Transfort, food hose: used for beer, edible oil and other liquid being absorpted in the room temperature and the taste and color will not change, conformed to the requirements of health food.

Data Sheet of Air Water General All Purpose Hose

ID (mm) ID (inch) Wall (mm) WP (bar) BP (bar) Radius (mm) Weight (kg/m)

6 1/4 3, 5 20 60 35 0.17

8 5/16 3, 5 20 60 50 0.25

10 3/8 3, 5 20 60 60 0.29

13 1/2 4, 0 20 60 60 0.37

13 1/2 5, 0 20 60 70 0.42

16 5/8 4, 0 20 60 80 0.45

16 5/8 4, 5 20 60 90 0.48

19 3/4 5, 0 20 60 110 0.58

19 3/4 5, 5 20 60 125 0.60

25 1 5, 0 20 60 130 0.72

25 1 5, 5 16 60 150 0.83

32 1-1/4 6, 0 20 60 230 0.94

38 1/1-2 6, 0 20 60 270 1.08

50 2 7, 0 20 60 400 1.80

Company Contact:

• Posted By: Hengshui Jianfeng Engineering Rubber Co.,LTD

• Phone: 8613323183257

• Address: Renmin road No.1657,Heng shui City,Hebei Province,China, hengshui , hebei , China

• Email:

• Business Description: Hengshui Jianfeng Engineering Rubber Co., LTD., a manufacturing company built

  in the year 1999, Located in the North of China, which is a professional manufacturer of water stop, waterproof materials and China association of rubber products waterproofing material association member units as well.

  Its annual production capacity is about 10000 tons.



  Our main products include: Waterproofing products as rubber waterstops, pvc water stops, Bentonite Waterstop; Bridge and road construction products as various

  Elastomeric bearings, bridge pot bearings, spherical bearings, bridge flexible equipment;

  Seismic isolation as lead rubber bearings, high damping rubber bearings, steel type seismic bearings and bridge expansion jont, Inflatable pipe plugs, etc.

  The company's operating philosophy is " Work once, Trust all lives ", relying on excellent technology, high quality products and excellent service to get the user's consistent high praise.

  Products are mainly used in water conservancy, electric power, environmental protection, ore smelting, machinery, municipal, transportation, airports, ports, stadiums, gardening and irrigation infrastructure industry.

  .

  in order to ensure product quality, not only has advanced testing equipment, and has passed ISO9001 international quality management system certification.

  The company established a perfect quality guarantee system, to ensure the engineering quality.

  We can also meet different standrad.
