High Performance Putty Sealant Made In China - China

I

Q: Can you introduce the GB flexible filler?

A:

GB flexible filler is a kind of special rubber as raw material.

It has a lot of characteristics, such as uniqueness, high plasticity, heat resistance, cold resistance, aging resistance and non-toxic and tasteless, water resistance, good adhesion performance and also it's easy to operate.

It is a new type of flow type of seal material which is produced for concrete face seal, the surrounding rock joint seal and the expansion joint sealing.

It is a key material of dam sealing surface.

It can also serve as a concrete building joint surface sealing material.

II

Q: What are the characteristics of the GB flexible filler?

A: The following are the characteristics of the GB flexible filler:

1 - It has excellent deformation and mobility.

It can flow under the action of water pressure and squeeze into the gap to the sealing effect.

Its anti permeability performance is excellent, and it has enclosed waterproof effect to pores and crack.

2 - It has good bonding performance.

Bonding strength of GB flexible filler with concrete is better then itself tensile strength, so that we can make sure bonding interface does not occur under various operating conditions.

3 - It has excellent resistance to medium, that is water proofing and alkali salt soak.

GB flexible filler has strong applicability to the environment.

It can resist to freezing and thawing cycle and has a certain cold resistance and high temperature resistance.


III

Q: What's the application range of GB flexible filler?

A:

1 - Expansion joint and peripheral joint of a variety of large and medium sized hydropower projects.

2 - Seal up of Large panel, expansion joints, and the joints of roof parapet.

3 - Waterproof sealing of basement, civil air defence works, tunnel subway, culvert and all kinds of water supply and drainage works.

4 - Bond seal of concrete and rubber, plastics, ceramics and all kinds of metal materials.


IV

Q: How to construct about GB flexible filler?

Cut out "V" type slot which is 8CM wide, 8CM deep for all kinds of joints and crack mouth.

The full removal of stone chips, dust and loose animal, filled with mortar uneven, and make it dry.

Before construction, rub the material into a thick strip close to the seam width.

And then fill up the joints on the dressing with that material, to make the deposited high surface be specified convex cylinder.

Finally cover the PVC protection cover plate.

Note: GB flexible filler can be processed into various shapes and sizes according to the needs, to make it easy for construction.

V

Q: What construction matters about the GB flexible filler should be attention to ?

A:

1 - Construction principle: First in the seam, after the seam, the first on both sides, after the middle.

2 - The construction of the base surface must be solid, dry.

3 - After the construction of sealing material, it shall be protected to avoid the operation of machinery.


VI

Q: What's the technical performance index of the GB flexible filler?

A:

Test item Control index GB flexible filler remarks

water proofing, Chemical resistance water ±3% +1.5% GB flexible filler in three solutions changes in the weight of five months of immersion

Saturated calcium hydroxide solution ±3% +1.8% 10% Sodium Chloride Solution ±3% +1.2%

Tensile property normal atmospheric temperature tensile strength(MPa)≥ 0.06 0.09 CL-GB flexible filler during tensile deformation

elongation at break(%)≥ 800 1196 The bonding surface of concrete has not been pulled apart

-30ºC tensile strength

(MPa)≥ 0.7 0.95 elongation at break(%)≥ 800 1078 density(g/cm3) ≥ 1.15 1.4 Water immersion on the surface of concrete The ratio of adhesive strength and reference value after three months(%) ≥ 95 98.8 environmental protection Rubber products Non-toxic, non polluting

300 times of freezing and thawing Ratio of strength to standard value of concrete(%) ≥ 90 97.5 Temperature range of -21 to +5 C fast freezing and thawing 300 times

Flow performance 75 degrees 60 degrees 48 hours Not flowing

Permeability resistance 10kg/cm2 water pressure 72 hours without water seepage
