Water Plugging Airbag Used To Prevent The Flow - China

Pipeline water blocking air bag Plugging water balloon and known as the pipeline plugging bag, pipe blockage, closed water test balloon, closed water blocking, pipeline plugging airbags, pipe occluder.

Plugging water bag is made by an enhanced natural rubber, every blocking water balloon before delivery will tested at 1.5 times the rated working pressure and the corresponding number of tube.

In order to ensure the plugging water bag structure strength, we adopt three times in plugging water bag of the rated working pressure of the safety factor.

Jianfeng pipeline plugging airbags are made of high-quality composite rubber and polymer materials, on the basis of the original product absorbing the advantages of foreign products, through the technological improvement of production and product innovation, in the use of performance, are more high, anti-aging, tight sealing, and adapts to a wide range of diameters and sealing speed, easy to operate than ordinary closed water airbags elastic.

(1)classification of Pipeline water blocking air bag i.

Water plugging air bag by function:

1, the pipeline plugging operation type: water blocking air bag is mainly used for pipeline maintenance and sealing construction.

2, the pipeline detection operation type: water blocking air bag is mainly used for pipeline closed water leakage detection construction.

ii.

Water plugging air bag by use of raw materials:

1, pure rubber type: water blocking air bag with natural rubber, rubber, rubber, butyl rubber, butyl rubber, made of pure rubber.

2, compound rubber: water blocking air bag using a variety of synthetic or natural rubber processing products.

3, skeleton material type: plugging water balloon with polyester, nylon, nylon, aramid fiber fabric is coated on the surface of rubber or other materials processing products.

iii.

Water plugging air bag according to molding process:

1, a curing molding process: the water blocking air bag on the curing tank or other curing equipment through a vulcanization molding products.

2, a number of curing molding process: a number of complex water plugging air bag after a cure is not finished, it uses a number of curing process.

3, the adhesion forming process: forming bonded together by a plurality of groups of film sheet with adhesive material connection.

4, heat vulcanization forming process: water plugging bag film by special equipment will be made of high temperature pressure of the adhesive.

iv.

Water plugging air bag by shape:

1, round;

2, cylindrical;

3, square;

4, oval;

5, egg shape;

6, hollow cylindrical.

v.

Water plugging air bag by using pressure:

1, no pressure: water blocking air bag is suitable for general drainage, sewage and other non pressure pipe plugging.

2, low pressure: water blocking air bag is suitable for general drainage, sewage and other pipeline acceptance test.

3, medium pressure: water blocking air bag is suitable for the repair of water supply pipeline operation.

4, high pressure: water plugging bag is suitable for oil and other pressure pipeline maintenance.

(2)Method of use:

Put plug into the need to plug the pipe mouth and the length of the pipe is put into the length of the plug.

then through the intake valve rushed into the compressed air to the required pressure can be constructed.

After the completion of construction after open the inlet valve to release air, remove plug.

(3)The model of the pipeline sealing air bag is: PVC gas nozzle capsule, compound type closed water plug, air nozzle type closed water plugging, and double different gas filled capsules.

Two glue a cloth(mm) Inflation pressure(Mpa) Three glue two cloth specifications(mm) Inflation pressure(Mpa)

Φ300×1000 0.045 Φ800×1200 0.06

Φ400×1000 0.040 Φ1200×1800 0.05

Φ500×1000 0.031 Φ1500×2000 0.05

Φ600×1000 0.028 Φ2000×2500 0.045

Φ700×1000 0.027 Φ2200×2800 0.03

Φ800×1200 0.026 Φ2500×3000 0.03 (4)Closed water plugging detection function:

1, the high-rise construction pipeline leakage test: capsule is fed by examination of the mouth, inflation after the inspection, such as pipeline chlamydia or saliva is not strict, you can see the leak test.

2, check the toilet: Capsule on the drain after inflation, such as rubber banding is not strict, water will leak from the interface.

3 - Check the floor drain: open the floor drain bowl, the capsule into the floor drain, inflatable splashing in the ground, such as the installation of floor drain not according to the provisions of the pallet filling ash plugging holes, water will be from around the floor drain leakage.

4, a variety of pipeline maintenance temporarily used to block water
