Durable Stable Optical Flap Gate Barrier Turnstile Access Control System Sus 304 Housing - China

price: check with company for price

Jiaxuntong Flap Barrier Description # Optical turnstile is designed to control pedestrians entering or exiting restricted areas, usually used of high pedestrian traffic flow in both directions.

# The body is made from brushed stainless steel which creates a seamless and elegant access point to blend into most indoor environment.

# It can be integrated with any kind of access controller system (e.

g: RFID device, Push button, Fingerprint and Biometric device).

# In case of emergency, the Optical Turnstile arm will open automatically to allow free passage.

# Optical Turnstiles are suit for elegant and luxury entrance solutions.

Specifications: - - - - Model No.

| CF238FLG-YH | Framework Material | 304 Stainless Steel | Dimension | 1400 * 320 * 980mm | Net Weight | 85kg | Passage Width | 550mm (One passage) | Passing Direction | Single directional / Bi-directional | Power Supply | AC220V/110V, 50/60Hz | Operation Voltage | 24V DC | Power Consumption | 40W | Operation Temperature | -15 C 60 C | Operation Humidity | 0 ~ 95% (No freeze) | Working Environment | Indoor / Outdoor (Shelter) | Flow Rate | 40-45 people per minute | LED Indicator | Yes | Input | Dry contact | Emergency | Automatic arm open when power off | Communication | RS485, TCP/IP | - - - - Features: # The whole system runs smoothly, long-life performance, high operation dependability and fast response.

# Alarm function, in case of illegal intrusion and reverse intrusion.

# Infrared sensor to prevent pinch pedestrians.

# Anti-breakthrough function.

The gate is locked automatically until opening signal received.

# Anti-trailing function, the turnstile will lock if someone wants to burst in without swiping the RFID card.

# LED indicator.

# Automatic reset function.

If the user fail to pass within the prescribed time (default time is 5 seconds), the system will cancel the authority of the current user automatically.

# When power off, optical turnstile will open automatically, which is complying with fire safety requirements.

Flap barrier different type : According to qty of the wing, it can be divided into one wing flap barrier and double wings flap barrier.

One lane combined by 2 pcs one wing flap barrier, two lanes combined with 2 one wing and 1 double wings flap barrier.

Package: 1 - Size: 1450x420x1100mm 2 - Gross Weight: 75KG 3 - Package: Export packing, plywood box


Company Contact:


  • Phone: 86-755-29838914

  • Address: 4th floor Hengling Industrial area Longhua district Shenzhen China, Shenzhen , guangdong , China

  • Email: Email


Published date: February 23, 2018

  • Business Description: Established in Y1998, Jiaxuntong computer technology Co., Ltd, is a professional developer and manufacturer of intelligent building access control system and high-end channel equipments including tripod turnstile, swing turnstile, flap turnstile, full height turnstile and speed gate.
