Product Parameters Of Air Cooled Xenon Lamp Aging Test Chamber - China

Product parameters of air-cooled xenon lamp aging test chamber Temperature range: RT+10℃～70℃

Humidity range: 65%～98%RH

Blackboard temperature: 63℃～100℃

Temperature uniformity: ≤2.0°C (in the dark)

Temperature fluctuation: ±0.5°C (in the dark)

Humidity deviation: +2, -3% RH

Nozzle diameter: Ф0.8mm

Rain water pressure: 0.12～0.15Mpa

Rainfall time: 1 ~ 999M, adjustable continuous rainfall

Spray cycle: 18min/102min or 12min/48min (spray time/spray stop time)

Photoperiod: 1～999h, m, s continuously adjustable

Sample tray size: 450×720mm

Distance between sample holder and lamp: 230～280mm

Wavelength: 290~800nm

Radiation intensity: ≤550W/㎡

Xenon lamp power: 2.5KW×3=7.5KW

Heating power: 3.0KW

Humidification power: 2.0KW

Outer box material: high-quality A3 steel plate electrostatic spray

Inner box material: imported high-grade stainless steel SUS304

Temperature and humidity controller: "Taiwan Weilun" touch screen + "German Siemens" PLC module

Temperature and humidity sensor: PT100 platinum resistance temperature measuring body

Standard configuration: 3 lamp tubes, 1 layer of sample rack

Safety protection: compressor overpressure, compressor overload, water shortage protection, fan motor overheating, overall equipment overtemperature, overall equipment phase loss/reversal, Overall equipment timing leakage protection, water shortage protection, automatic shutdown after fault alarm and other protections

Power supply voltage: AC380V±10% 50Hz

Power: 14.5KW

Operating environment: 5℃～＋28℃ ≤85% RH ps: (WLJCDM809)
