This is a Non-stop punching with high efficiency Speedway Guardrail Roll Forming Machine .

It can be used in a variety of guardrail, such as guardrail, highway guardrail, fence and other livestock farms.

The equipment is mainly composed of decoiler, punching unit, roll former, cutting device, product table, and control cabinet, etc.

This Speedway Guardrail Roll Forming Machine adopts automatic PLC control and touch screen operation.

And it has high speed forming process and makes little noise.

The equipment adopts welded frame of high intensity.

After fine finish, forming rollers get heat treatment before chromeplate.

So this equipment has features of stable performance and long service life.

Technical parameters for Speedway Guardrail Roll Forming Machine

Raw material Q 235

Yield strength 235 Mpa

Material thickness 3-4 mm

Material width ＜500 mm

Coil ID Ф508±20 mm

Coil OD ≤Ф1200 mm

Coil capacity ≤ 5 T

Production speed 3-10 M/MIN

Length tolerance ±2 mm

Power 380 V±10%; 50-60 HZ.

Total Power 90 KW

Working Flow

Decoiler → Leveling And Guiding → Server Motor Feeding → Punching → Roll Forming →

Cut Off Non-Stop Machine To Length → Finished
