Glass Fibre Reinforced Polyamide Thermal Barrier Strip For Insulated Window System - China

High precision 24mm shape I PA6.6 25% fiberglass curtain walls thermal broken strip for windows and doors.

Inserted in the thermal break aluminium profiles, and being the part of energy-saving window system for reducing heat conduction.

The shape T polyamide thermal barrier material can prevent the window frame from dust and water, also has a more firmness mechanical performance than the shape I, could realize a better Uf value by sealing with a rubber profile, mostly used on the sash.

Technical performance: The performance of thermal barrier strips are in line with the Chinese standard GB/T 23615.1-2009 and the European Standard EN 14024: 2004, for KAXITE series, the performance is rather higher than the standard value.

Details of related standard: GB/T 23615.1-2009 Accessorial material for architectural aluminum alloy profiles -- Part 1: Thermal barrier strip of polyamide

EN 14024-2004 Metal profiles with thermal barrier -- Mechanical performance Requirement, proof and tests for assessment

YS/T 437-2008 Aluminium profiles moment of inertia calculation methods and computing software requirements

JG/T 174-2005 Thermal barrier strips for construction industry

GB 5237.6 -2012 Wrought aluminium alloy extruded profiles for architecture -- Part 6: Thermal barrier profiles

GB/T 8478-2008 Aluminium windows and doors

GB/T 8484-2008 Graduation and test for thermal insulating properties of doors and windows

JG 175-2011 Insulating aluminum alloy profiles with thermal barrier for buildings

UL94 Standard for Tests for Flammability of Plastic Materials for Parts in Devices and Appliances

ASTM E84 Standard Test Method for Surface Burning Characteristics of Building Materials

NFPA 285 Standard Fire Test Method for Evaluation of Fire Propagation Characteristics of Exterior Non-Load-Bearing Wall Assemblies Containing Combustible Components

In 2015, we became the leader of the Chinese National Standard Committee (for revising of GB/T 23615.1-2009) .

(KAXITE Series)(made of pure new raw material of PA66), you can see the extremely better performance of thermal break polyamide strips as shown below:

For Insulated Window System Pa6.6 25% Fiberglass Thermal Barrier Profile Raw Materials & Granulation:

We granuled by ourselves to ensure the quality of raw material for PA66GF25 thermal insulation strips.

What's the most important component in the raw material of Heat Insulation Profiles for windows & doors? Not Dupond, not extremely expensive fiberglass, it's Anti-aging agent and Antioxidants.

Think what will happen if there's no such anti-aging agents or antioxidants? Heat Insulation Profiles for windows & doors may aging fastly under wind and sun, maybe just less than 10 years, the polymer profiles would broken and glasses and windows will fall from such high curtain walls!! It's killing! But now most finished raw materials in the market for thermal barriers manufacturers have no such antioxidants due to it's high cost, so in order to avoid the phenomenon, we have our own capacity of granulation to ensure that our raw materials contain these important elements! OEM of Performance (Granulation)! We support customizing any special performance of polyamide thermal break strips, even flame retardant required.

OEM of Shapes (cutting dies)!

Mostly we could finish the development of new products in 15 days.

The hardest thing is not thinking, but realizing.

Most customers were upset that nobody could develop the shapes that they designed, some counterparts even came and looking for help to our workshop.

We developing and cutting new dies for our customer, of course we never failed to develop any shape for our customers.

service advantages: 1, the design and development of new insulation strips, for any kinds of shapes you need for the Heat Insulation Profiles for windows & doors, we can develop mould in a short time and send you the samples, actually we’ve successfully solved so much headaches for our customers and received satisfaction; 2, we offer the most advanced laser marking machine for custmers if a special mark on the heat insulation strip is needed; 3, Here we offers most sizes from 10mm width to 60mm or even bigger heat insulating strips, which’s your best favor? 4, We provide matching equipment of PA66 thermal barrier profiles for customers for the corresponding service followed.

storage conditions: It’s better to be stored in ventilated and dry environment, should be put horizontally, keep away from water, rain, heat, stress, and avoide acids, alkalis and organic solvents meanwhile.

Packing: Straight: 6 m / bar, 10~100 pieces per bundle as you like.
