Heat Strengthened Glass For Laminated - China

1Heat Strengthened Glass 15mm Heat Strengthened Glass

Heat Strengthened Glass for laminated glass Heat-strengthened glass differs from tempered glass in surface compression; its mechanical strength is about 1.6-2 times that of annealed glass.

Specification Properties Heat-Strengthened Glass

Thermal Shock Resistance Up to 130°C

Mechanical Strength Two times stronger than annealed glass

Fragmentation Knife Edges

Tensile Strength 40-55 MPa

Bending Strength 40 N/mm2

Design Stress for Architectural Purpose 17 MPa

Features

1 - Heat-strengthened glass differs from tempered glass in surface compression; its mechanical strength is about 1.6-2 times that of annealed glass.

2 - Heat-strengthened glass has outstanding thermal stability, its flatness and light transmission is close to that of annealed glass and much better than that of tempered glass.

3 - HS Glass is 3 times more resistant to thermal stress in comparison to normal annealed glass.

4 - It can withstand temperature difference of 100°C (in range of 50°C to 150°C) compared to ordinary annealed glass which can withstand up to 40°C.

5 - Heat strengthened glass is that it is far less susceptible to spontaneous breakage.

Application

Heat-strengthened glass is widely used in laminated glass for additional strength, such as in overhead and sloped glazing.

Company Contact:

• Posted By: Glorious Future Glass Co., Ltd

• Phone: 86 10 87156878

• Address: No.868 Shibalidian Town, Chaoyang District 100023, Beijing China, Beijing , Beijing , China

• Email:

• Business Description: Glorious Future Glass Co., Ltd is the most professional engineering glass manufacturer in northern China, we are committed to offer satisfying products and service, being your reliable engineering glass supplier is our honor.

  Professional skilled staffs with average 8 years experience are our precious fortune; we love glass and treat glass as part of life, producing every piece glass just like cultivating our children.

  Our Beijing factory was built since 2004, the advantage is deep processing 10-25mm ultra large glass, we have 2 production lines of full automatic glass cold working, 1 production line of hot working, 1 super-large type laminating production line which can do heat soak test and the largest dimension is 12, 000mm*3200mm.

  In 2010, we invested around 100 million to build another factory in Qingdao and brought in advanced equipment from Leybold, Bentler, Huettinger, Siemens, Alcatel, MKS, and built magnetron sputtering coating line with 15 sets double sputtering cathodes, annual production capacity is 3, 000, 000sqm heat reflective glass and tempered single & double silver Low-E glass.

  The max size is 7500*2440mm, thickness is 5-15mm.

  8 members R&D team with over 10 years experience in optics, inorganic molecular materials, and structural field support us continual development.

  Our glass approved by CCC, ISO9001, CE, and authenticates on the spot through SGS.

  We keep the promise “being your most reliable engineering glass” and commit to the belief “practical, integrity”.
