Steam Insulation Pipe - China
price: contact company for price
Steam Insulation Pipe
PRODUCT PARAMETERS
Main Performance Index
Performance index Reference standard Unit Standard requirement
Finished pipe combination
Appearance CJ/T200-2004 No obviouspits, bulges, cracks
Work pipe axial movement CJ/T200-2004 No jam can move
Outer protection pipe temperature CJ/T200-2004 ℃ ≤50
Heat loss CJ/T200-2004 W/ m ≤100
Overall compressive strength CJ/T200-2004 MPa ≥0.08
Axis eccentricity CJ/T200-2004 mm 4/5/6
Vacuum absolute pressure (Vacuum type) CECS206-2006 mbar 20
Extra-fine glass wool
Density CJ/T200-2004 Kg/m 48
Maximum working temperature CJ/T200-2004 ℃ 454
Thermal conductivity CJ/T200-2004 W/m.
k ≤0.05
Average fiber diameter CJ/T200-2004 μm 6
Water tolerance CJ/T200-2004 100 degrees of boiling water No significant changes in physical
Anti-moisture CJ/T200-2004 Expose 96h Moisture is less than the product weight
Anti-corrosion CJ/T200-2004 For steel No corrosion
Fire proofing CJ/T200-2004 Non inflammability Grade A
Steam Insulation Pipe factory: Tianjin Haimen Building Materials Co., ltd
PRODUCT FEATURES
Product name Steel jacket steam insulation pipe
Wall Thick 0.5mm-16mm, or customized
Length 1m-12m, or by customer's requirements
Laid way Buried, overhead, trench
Production Standard CJ/T200-2004, CJJ104-2005
Packing Plastic cap for both end, steel strips bundled
Application Urban central heating Petroleum, chemical, power high temperature
Quality Control 100% X-Ray inspection 100% Hydraulic Pressure test 100% Ultrasonic inspection
TECHNICAL INDICATORS
Nominal diameter OD hickness(mm) Outer protection tube diameter all thickness(mm) Insulation thickness(mm)
25 32x3 90x2.3 29
32 43x3 110x2.5 33
40 48x3 110x2.5 31
50 57x3 125x2.5 34
65 76x3.5 140x3 33
80 89x4 160x3.0 33
100 108x4 200x3.2 36
125 133x4.5 225x3.5 46
150 159x4.5 250x3.9 45.5
200 219x6 315x4.9 48
250 273x6 365x5.6 46
300 325x7 420x7 47.5
350 377x7 500x7.8 61.5
400 426x7 550x8.8 62
450 478x7 600x9.8 61
500 529x7 655x9.8 63
600 630x8 760x11 65
700 720x8 850x12 65
800 820x9 960x13 70
900 920x10 1054x14 67
1000 1020x12 1155x14 77
1200 1220x12 1380x15 80
1400 1420x14 1680x16 114
Company Contact:
- Posted By: Tianjin Haimen Building Materials Co.,ltd
- Phone: 022-65265758
- Address: No. 2352-600 Tanghan road, Tanggu marine science and technology park,, Tianjin , Binhai high-tech zone, China
- Email:
- Website: https://www.insulatchina.com
Published date: November 11, 2019
- Business Description: Tianjin Haimen Building, founded in 1987, formerly a military enterprise, restructuring and renaming as Tianjin Haimen Building Materials Co., Ltd. in 2010 - Haimen Located in #2352-600 Tanghan Road, Binhai New Area, Tianjin China, close to the Tianjin seaport.
The registered trademark is "Haimen" brand, focus on R&D, production, construction and service of thermal insulation materials.
With the principle of "focus, professionalism and specialization", obtained the ISO9001 QMSA certificate in 2003, and then passed the ISO14001 Environmental Management System and OHSAS18001 Occupational Health and Safety Management System Certification, and have the Grade II Qualification Certificate of The National Antiseptic Insulation Project Construction.
With the philosophy of "not selling future with short-term interests, with quality goods to participate the market competition", provide quality products and excellent services, sincerely expect friends from all circles to consult and negotiate businesses, seeking common development.
