Factory Sale Booster Pump N2 O2 Other Corrosive Gas - China

STA SERIES

Description

Single-acting, Single stage

Max pressure: 800 bar

Max flow: 1000L/min

Driving air pressure: ≤8 bar

Driving piston diameter : 160 mm

Aluminum alloy and stainless steel Features

Operational safety: Gas driven, no electricity required, simple operation, automatic pressure holding

Wide applications: Suitable for most gases, standard & custom systems available

Long service life: No limit or adverse affect to continuous stop/start applications, seal systems designed for long working life Applications

Pressure test with gas

Gas transfer & recovery

Charging of nitrogen accumulators

Supply for isolating gas systems

Gas assisted injection molding

CO2 foaming

Transfer of oxygen cylinders

Charging of breathing air bottles

Leak test FAQ

Q: How do I choose the right product?

A: You can choose the type of pump by determining whether your medium is gas or liquid, and according to the pressure and flow rate you need to select the specific model or you can contact us directly and we will recommend the right product for you Q: When can l get the price?

A: Usually we quote within 12 hours after we get your enquiry Q: Can you accept OEM?

A: Yes, we can accept OEM, manufacture according to your request, label you logo or offer Neutral packing without our logo and information.

Q: What about the delivery date?

A: Usually we offer 1-2 weeks after order confirmed and payment received, and we can also accept urgent order for prompt shipment.

Q: What about the M.O.Q?

A: Usually we do not have M.O.Q, we can offer even only 1 unit, while, you are welcome to order in bulk, and we are quite pleasure to offer pleasant outstanding discount Q: What about the after-sale service?

A: Guarantee period is 12 months, after the warranty, we also provide life-long paid repair or service.

Company Contact:

• Posted By: Shandong Shineeast Fluid Control Systems Co., Ltd.

• Phone: +8619725317715

• Address: Gaoguanzhai Town, Jinan , Shandong , China

• Email:

• Website: https://cnshineeast.com/about.html

• Business Description: SHINEEAST Company has more than ten years of hydraulic and pneumatic engineering experience in the design and manufacture of air driven liquid pumps.

  Continuous investment in new machinery and advanced technology imported keeps SHINEEAST at the forefront of the field.

  We offer the most complete range of models in the industry measured for:

  A.

  Capability of ultimate pressure, flow or output horsepower.

  B.

  Compatibility with a broad variety of liquids, such as oil, water and chemical applications.

  SHINEEAST pumps are air driven at a drive air pressure of 2 to 10bar (29 to145 psi).

  However, we advise the pressure within 8bar for service life of the pumps.

  Basically the principle of operation is similar to a reciprocating amplifier where control of the piston at the end position is regulated by a pilot operated 4/2 way valve.

  SHINEEAST pumps feature a large air piston joint to a smaller diameter plunger.

  The pressure ratio is the difference of these two areas and is the method of determing maximum outlet pressure.

  Higher pressure

  is obtained by using higher pressure ratio.

  SHINEEAST model numbers reflect the pumps nominal pressure ratio, while the technical data indicates exact ratios.

  The outlet pressure is easily to set through a simple air regulator.

  By multiplying the pressure ratio by the available shop air pressure, the nominal liquid pressure can be calculated.

  SHINEEAST pumps are self priming.

  In general it is not necessary to use an air line lubricator.

  The liquid

  is pumped, flows into the suction chamber by the up-stroke of the drive piston.

  By this suction effect, the inlet check valve is opened and the outlet check valve is closed.

  The down-stroke generates the pressure at the liquid side.

  The inlet check valve is closed and the outlet check valve is opened by the generated pressure.

  SHINEEAST liquid pumps cycle automatically, where the pressure is built up the numbers of cycles slow down, the pump stops automatically when the output pressure forces are equal.

  The pump restarts with a slight drop in the outlet pressure or an increase in the air drive pressure.

  Pump performance can be affected by a number of conditions, such as freezing of muffler or pilot valves (which is caused by moisture in air lines), inadequate inlet air line sizes and dirty filers.

  Don’t reduce the indicated port sizes and consult SHINEEAST for exact flow conditions not shown in charts.

  SHINEEAST offers complete technical and service support for all SHINEEAST pumps.
