Rdh315 90 Butt Fusion Welding Machine - China

RDH－315/160 Hydraulic Butt Welding Machine

Application:

Suitable for butt fusion welding of plastic pipes and fittings made of PE, PP, and PVDF in construction site or workshop.

Features:

1 - consists of basic frame, heating plate, planning tool, and support (for planning tool & heating plate) 2 - Removable PTFE coated heating plate with separate temperature control system.

3 - Electric milling cutter with reversible double cutting edge blades.

4 - Low starting pressure ensures reliable welding quality of small pipes.

5 - Hydraulic unit provides welding machine with compressing power.

6 - It is made of lightweight and high strength material; light weight, simple structure and easy to operate

7 - Separate two-channel timer shows time in soaking and cooling phases.

8 - High-accurate and shockproof pressure meter indicates clearer reading.

\

Technical parameter:

 Welding ranges: plastic pipes: 160mm－315mm

(160mm－180mm－200mm －225mm－250mm－280mm� ��315mm)

 Extended to 160mm－315mm

 Ranges of application: PE, PP and PVDF

 Working voltage: ～220V ±10%, 50Hz.

 Total power: 4.95 kW, including: planning tool：1.1 kW, heating plate：3.1 kW, hydraulic unit motor: 0.75kW  PTFE coated heating plate, adjustable knob for temperature control, difference in heating plate surface temperature ≤±7°.

 Environment temperature: －10° ～ 45°

 Electronic count-down timers for heating and cooling time.

 Whole machine consists of basic frame, heating plate, planning tool, hydraulic unit and support (for planning tool & heating plate)

Company Contact:

• Posted By: WUXI YUDA PLASTIC PIPE WELDING MACHINERY FACTORY

• Phone: 8618921353365

• Address: QIANZHOU TOWN, WUXI , China

• Email:

• Website: https://www.cnbuttfusion.com

• Business Description: Wuxi Yuda Plastic Pipe Welding Machinery Factory located at Wuxi in Jiangsu.

  Since established in 1995, is growing one of the largest welding manufacturer in China, Yuda is an enterprise not only devoted to plastic pipe welding technology and research, design, manufacture, sales, training and maintenance of plastic pipe welding equipment, providing the customers with full and best service, but also has rich experience in aluminum casting process, such as inserts, clamps, heating plate and trimmer which produced by ourselves.

  Our product includes Field butt fusion welding machine, Full-Automatic Multi-angle fitting welding machine, Multi-angle cutting machine, Saddle fusion machine, Arched surface cutter, butt welding machine with data logger and printer, Full-Automatic butt fusion machine, Drainage Welding Machine and Special assistant tools for PE and PP pipes construction etc.
